AZ-2000-IECW: Advanced ESD Paint for Aerospace and Beyond
May 7, 2025

Manufactured with Speed and Precision
The manufacturing capabilities you need and the engineering support you want, all from a single partner.
Submit a DesignKey Points
- AZ-2000-IECW combines superior thermal control properties with electrical conductivity, offering protection against electrostatic discharge in demanding environments.
- This specialized ESD paint maintains its performance in extreme temperatures ranging from -356°F to 1832°F, making it ideal for aerospace applications.
- The inorganic composition provides exceptional durability and resistance to atomic oxygen degradation compared to traditional organic coatings.
- With a surface resistivity of 10^4-10^6 Ω/sq, this coating effectively dissipates surface charges while maintaining optimal thermal properties.
- Engineers working on satellite systems and spacecraft can benefit from the dual functionality of thermal control and electrostatic discharge protection in a single coating solution.
Understanding ESD Paint in Aerospace Applications
Electrostatic discharge poses significant risks to sensitive electronic components, particularly in aerospace environments where repair options are nonexistent after deployment. ESD paint provides a critical protective layer that prevents damaging charge buildup on component surfaces.
AZ-2000-IECW stands apart from conventional thermal control coatings by combining robust ESD protection with exceptional thermal management capabilities.
Visit the Resource Center: Advanced Coatings for Aerospace Optics
Definition
What is AZ-2000-IECW?
AZ-2000-IECW is an inorganic conductive white thermal control ESD paint that provides superior electrical conductivity while maintaining excellent thermal properties for spacecraft applications. Operating in extreme temperatures from -356°F to 1832°F, this specialized coating offers both effective surface charge dissipation and atomic oxygen protection with a surface resistivity of 10^4-10^6 Ω/sq and thermal emittance of 0.88 ± 0.02.
This specialized coating addresses multiple challenges faced by aerospace engineers. Traditional thermal control paints often sacrifice electrical conductivity, forcing engineers to make difficult design compromises. AZ-2000-IECW eliminates this tradeoff by providing both properties in a single solution, streamlining the material selection process for mission-critical applications.
Technical Specifications and Performance Metrics
AZ-2000-IECW delivers precise performance parameters critical for aerospace applications. Engineers designing systems for space environments require materials with exact specifications to ensure mission success. The following table outlines the key performance metrics:
Property | Value | Significance |
Surface Resistivity | 10^4-10^6 Ω/sq | Provides effective ESD protection |
Thermal Emittance (εt) | 0.88 ± 0.02 | Excellent heat dissipation capability |
Solar Absorptance (αs) | 0.25 ± 0.02 at ≥3.0 mils | Low heat absorption from solar radiation |
Operating Temperature Range | -356°F to 1832°F | Functions across extreme temperature variations |
Appearance | Non-specular white | Reduces glare while maintaining reflective properties |
Nominal Dry Thickness | 4.0 ± 1.0 mils (over 85% of area) | Consistent coverage for uniform performance |
ASTM D3359A Adhesion | Not less than 3A | Strong adhesion to substrate materials |
Full Cure Time | 7 days | Complete development of specified properties |
These specifications make AZ-2000-IECW ESD paint particularly valuable for systems that must operate reliably in vacuum conditions with extreme temperature fluctuations. The combination of high emittance and low absorptance creates an optimal thermal profile for spacecraft components.
Deep Dive: What is Thermal Emittance?
Discover the critical role thermal emittance plays in spacecraft temperature regulation in our comprehensive technical guide.
Learn MoreDeep Dive: What is Solar Reflectance?
Explore how solar reflectance impacts thermal management systems in aerospace applications in our detailed engineering analysis.
Learn MoreDeep Dive: What is Solar Absorptance?
Learn why precise solar absorptance values are essential for mission success in our expert breakdown of thermal control coatings.RetryClaude can make mistakes.
Learn MoreRead the guide: Optical and Thermal Coatings in Aerospace
Composition and Environmental Considerations
AZ-2000-IECW features an inorganic composition that distinguishes it from traditional organic thermal control coatings. This formulation provides significant advantages for engineers working with materials that must withstand harsh space environments.
The inorganic structure of this ESD paint offers:
- Exceptional resistance to atomic oxygen degradation
- Superior stability under UV radiation exposure
- Minimal outgassing in vacuum environments
- Extended service life compared to organic alternatives
- Resistance to degradation from charged particle radiation
The absence of volatile organic compounds makes this ESD paint environmentally responsible and safer for application teams. Engineers can specify AZ-2000-IECW with confidence that it meets increasingly stringent environmental regulations while still delivering mission-critical performance.
Application Guidance for Optimal Performance
Achieving optimal performance from AZ-2000-IECW ESD paint requires precision application expertise and specialized equipment. Modus Advanced's engineering team delivers consistent, high-quality coating applications that ensure your sensitive electronic components achieve the full performance potential of this advanced material.
Surface Preparation and Application
Proper substrate preparation forms the foundation for successful ESD paint application. Modus Advanced's certified technicians follow these essential steps:
- Remove all contaminants including oils, particulates, and previous coatings
- Ensure surface is completely dry before application
- Apply appropriate primer if recommended for specific substrate
- Create uniform surface texture for consistent adhesion
- Maintain appropriate environmental conditions during preparation
Thorough preparation prevents common issues like delamination and inconsistent electrical performance. Our engineering team documents preparation processes carefully to ensure repeatability across production runs.
Our quality control systems maintain consistent thickness across the entire surface area, ensuring uniform electrical and thermal properties. With Modus Advanced handling your coating application, you eliminate the variability and risk of in-house application attempts.
Our approach to supporting your AZ-2000-IECW ESD paint requirements includes:
- Engineering consultation during the design phase
- Material selection guidance based on specific mission requirements
- Quality control processes that meet aerospace standards
- Vertical integration capabilities to streamline your manufacturing process
- AS9100 and ISO 9001 certified processes to ensure consistent quality
- ITAR compliance for sensitive projects
Curing Process
The curing process significantly impacts the final performance characteristics of the ESD paint. Modus Advanced's controlled curing environments ensure:
- Precisely maintained temperature and humidity during initial cure
- Monitored full 7-day cure process before release
- Protection from contamination during the curing period
- Continuous monitoring with advanced quality control methods
- Comprehensive documentation for quality assurance
Complete curing is essential for achieving the specified electrical and thermal properties. Our dedicated facilities and expert staff eliminate variables that could compromise the performance of your ESD paint application, particularly its critical ESD protection capabilities.
Performance in Space Environments
NASA technical reports have validated the performance of AZ-2000-IECW ESD paint specifically for auroral orbiting satellites. This endorsement highlights the coating's ability to maintain its protective properties in one of the most challenging operational environments.
Space environments present unique challenges that conventional coatings cannot withstand:
- Atomic oxygen erosion at low Earth orbit
- Extreme thermal cycling between sun and shadow
- Charged particle radiation from solar activity
- Micrometeoroid and orbital debris impacts
- UV radiation degradation
AZ-2000-IECW maintains its electrical and thermal properties despite these conditions, making it an ideal ESD paint solution for long-duration space missions. Engineers developing hardware for these applications can rely on its proven performance record.
Comparative Advantages Over Alternative Solutions
When evaluating thermal control and ESD protection options, engineers must consider multiple performance factors. AZ-2000-IECW offers distinct advantages compared to alternative approaches.
Advantages Over Traditional Thermal Control Coatings
Standard thermal control paints typically lack electrical conductivity, creating potential for damaging charge buildup. AZ-2000-IECW ESD paint eliminates this limitation while maintaining excellent thermal properties.
Specific advantages include:
- Integrated ESD protection without sacrificing thermal performance
- Reduced system complexity by eliminating separate discharge paths
- Simplified testing and qualification procedures
- Consistent performance across a broader temperature range
- Longer service life in radiation environments
These benefits translate directly to improved system reliability and reduced integration complexity. Engineers can simplify their designs while enhancing overall performance.
Advantages Over Conventional ESD Solutions
Traditional ESD materials often compromise thermal properties to achieve electrical conductivity. AZ-2000-IECW delivers both capabilities without this tradeoff.
Key advantages over conventional ESD solutions include:
- Superior thermal emittance for improved heat rejection
- Lower solar absorptance for reduced heat gain
- More consistent electrical properties across temperature extremes
- Better resistance to environmental degradation
- Higher temperature capability
This combination makes AZ-2000-IECW ESD paint particularly valuable for applications where thermal management and electrostatic protection are equally critical.
Terrestrial Applications Beyond Aerospace
While developed for space applications, AZ-2000-IECW ESD paint offers significant benefits in demanding terrestrial applications as well. Engineers working in various sectors can leverage its unique combination of properties.
Potential terrestrial applications for AZ-2000-IECW ESD paint include:
- High-altitude aircraft components
- Sensitive electronic manufacturing environments
- Telecommunications infrastructure
- Medical equipment requiring both thermal management and ESD protection
- Scientific instruments operating in extreme environments
- Defense systems exposed to harsh operational conditions
The superior durability and performance characteristics make this ESD coating paint suitable for any application where traditional coatings fail to provide adequate protection. Engineers should consider AZ-2000-IECW whenever conventional solutions struggle to meet complex requirements.
Partner with Modus Advanced for Your ESD Paint Applications
At Modus Advanced, we understand the critical nature of materials selection for applications where failure is not an option. Our engineering team has extensive experience working with specialized coatings like AZ-2000-IECW ESD paint and can help ensure your implementation achieves optimal results.
Our approach combines technical expertise with practical manufacturing knowledge, allowing us to support your project from initial design through production. We work with you to understand your specific requirements and develop application processes that deliver consistent, reliable performance.
When lives depend on your innovation, choose a partner who understands what's at stake. One day matters when you're bringing life-changing products to market. Contact our engineering team today to discuss how AZ-2000-IECW ESD paint can enhance the performance and reliability of your sensitive components.
