Key Points
- AZ-93 is a specialized inorganic white thermal control coating developed for spacecraft and satellite surfaces exposed to the harsh space environment
- With a solar absorptance (αs) of 0.15 ± 0.02 and thermal emittance (εt) of 0.91 ± 0.02, AZ-93 offers exceptional thermal control properties
- This ESD paint creates a bendable ceramic coating that has proven stable against atomic oxygen, charged particle radiation, and vacuum ultraviolet radiation
- AZ-93 has been used on the International Space Station for over a decade, including on NASA logos and navigation targets
- Understanding the technical specifications and application requirements is crucial for engineers working with ESD paint in aerospace applications
- AZ-93 is more cost-effective compared to alternatives like AZW/LA-II, making it an attractive option for ESD paint applications with budget constraints
The Critical Role of Thermal Control in Space Applications
Space presents one of the most challenging environments for engineered materials. Temperature fluctuations, radiation exposure, and the vacuum environment can rapidly degrade standard coatings. AZ-93 white thermal control and electrostatic dissipative (ESD) paint addresses these extreme conditions with specialized formulation.
The performance of spacecraft components depends significantly on thermal management. Without proper thermal control coatings like specialized ESD paint, sensitive electronic components and structural elements can fail prematurely when exposed to the harsh space environment. Engineers designing for space applications must carefully consider these factors when selecting appropriate thermal control solutions.
Visit the Resource Center: Advanced Coatings for Aerospace Optics
What is AZ-93 ESD Paint?
AZ-93 is an inorganic white thermal control ESD paint specifically engineered for spacecraft and satellite surfaces. This specialized esd coating creates a non-specular white surface that provides superior thermal protection in the space environment.
The formulation incorporates a highly stabilized pigment system with a silicate binder to create a bendable ceramic coating. This structure gives AZ-93 ESD paint its exceptional durability and performance characteristics that have been repeatedly validated in space missions. The esd coating allows only 13-17% of solar radiation to penetrate while emitting 89-93% of internal heat to space.
AZ-93 ESD paint has an extensive flight heritage, having been used on the International Space Station for over a decade. A precursor to this ESD paint was flown on the Long Duration Exposure Facility (LDEF) and returned after 5.8 years in orbit with minimal degradation in solar absorptance. This proven performance makes AZ-93 a trusted choice for critical space applications requiring reliable ESD protection.
Technical Specifications of AZ-93
Understanding the precise technical parameters of AZ-93 ESD paint is essential for engineers working on aerospace applications. The following specifications define the performance characteristics of this specialized coating.
Parameter |
Specification |
Solar Absorptance (αs) | 0.15 ± 0.02 at ≥ 5.0 mils thickness |
Thermal Emittance (εt) | 0.91 ± 0.02 |
Nominal Surface Resistivity | Not Applicable |
Use Temperature Range | -180°F to 2552°F |
Appearance/Color | Nonspecular white |
Nominal Dry Thickness | 5.0 ± 1.5 mils (over 85% of coated area) |
ASTM D3359A Adhesion Grade | Not less than 3A |
Full Cure | 7 days |
These specifications represent the cured properties of AZ-93 ESD paint, which engineers must consider when incorporating this coating into their designs. While this ESD paint does not have a specified nominal surface resistivity, its thermal control properties make it ideal for space applications where temperature management is critical.
Performance in Space Environment
AZ-93 ESD paint has undergone extensive testing to validate its performance in the harsh conditions of space. This testing demonstrates why this particular ESD paint formulation has become a standard for thermal control in spacecraft applications.
NASA has exposed AZ-93 to various space environment conditions including:
- Atomic oxygen (AO) fluence of 5.6 x 10^22 atoms/cm²
- Charged particle radiation of 4.5 x 10^15 e-/cm²
- Vacuum ultraviolet (VUV) radiation (from 118 nm to 170 nm) of 701 equivalent solar hours
After this extensive testing, the ESD paint showed remarkable stability:
- Less than 4% deterioration in solar absorptance (αs)
- Less than 1% change in thermal emittance (εt)
These results demonstrate why AZ-93 ESD paint has been selected for critical applications on the International Space Station and numerous satellite programs. Engineers can rely on this ESD paint to maintain its thermal control properties even after extended exposure to the space environment, ensuring the longevity of mission-critical systems.
Read the guide: Optical and Thermal Coatings in Aerospace
Application Guidelines for AZ-93
Proper application of AZ-93 ESD paint is crucial to achieve its specified performance characteristics. Engineers should follow these guidelines to ensure optimal results when specifying or working with this specialized coating.
The application process requires attention to several key factors:
- Surface preparation must be thorough to ensure proper adhesion
- Application should achieve a nominal dry thickness of 5.0 ± 1.5 mils over at least 85% of the coated area
- Full cure requires 7 days under appropriate conditions
- Adhesion should meet ASTM D3359A Grade 3A or better
Modus Advanced offers specialized application services for AZ-93 ESD paint, ensuring consistent and high-quality results for aerospace components. Our vertically integrated manufacturing process allows for complete control of the application environment, resulting in more reliable coating performance. With Modus handling your AZ-93 application needs, you benefit from:
- Environmental control during application to prevent contamination
- Precision application equipment for consistent coating thickness
- Trained technicians experienced with aerospace-grade coatings
- Comprehensive quality control and testing throughout the process
- Documentation that meets aerospace industry requirements
- Faster turnaround compared to using multiple vendors
Engineers should note that AZ-93 ESD paint forms a bendable ceramic coating after curing, which contributes to its durability in space applications. This unique property makes it suitable for surfaces that may experience thermal cycling or minor flexing during launch or deployment.
Proper application is essential to achieve the specified thermal control properties of this ESD paint. Even minor deviations in application techniques can affect the final performance characteristics.
Comparing AZ-93 to Alternative Coatings
When selecting an appropriate ESD paint for space applications, engineers must consider how AZ-93 compares to alternative coatings. This comparison helps in making informed decisions based on specific mission requirements and constraints.
AZ-93 offers several advantages compared to other thermal control coatings:
- More cost-effective than AZW/LA-II, though the latter has extremely low solar absorptance
- Proven long-term stability in space environment
- Extensive flight heritage on the International Space Station
- Better performance than many organic-based ESD paint formulations in radiation environments
When evaluating ESD paint options, engineers should consider these factors alongside budget constraints and specific mission requirements. For many applications, AZ-93 represents an optimal balance of performance, reliability, and cost.
The choice between different ESD paint formulations ultimately depends on the specific thermal control requirements of each mission. AZ-93 provides a well-documented and reliable option with extensive flight heritage.
Real-World Applications of AZ-93
AZ-93 ESD paint has been successfully deployed in numerous space missions, demonstrating its effectiveness and reliability. Understanding these applications helps engineers appreciate the versatility and proven performance of this specialized coating.
Notable applications of AZ-93 ESD paint include:
- External surfaces of the International Space Station, including all NASA logos
- Materials International Space Station Experiment (MISSE)
- The MIR MEEP POSA-I experiment
- Optical Properties Monitor (OPM)
- Various satellite thermal control systems
These applications span more than a decade of successful deployment in the space environment. The continued use of AZ-93 ESD paint on critical space hardware testifies to its effectiveness as a thermal control solution.
Engineers can draw confidence from this extensive flight heritage when specifying AZ-93 for new missions. The proven track record of this ESD paint in actual space applications provides assurance of its performance capabilities under the most demanding conditions.
Engineering Considerations for Implementation
When incorporating AZ-93 ESD paint into spacecraft designs, engineers must consider several technical factors that can affect performance and application success. These considerations help ensure the coating will perform as expected in the final application.
Important engineering considerations include:
- Substrate compatibility and surface preparation requirements
- Thermal cycling effects on the interface between the substrate and coating
- Application technique impacts on final thermal control properties
- Cure time and environmental conditions during curing
- Quality control procedures to verify coating thickness and uniformity
- Interface with other materials and potential galvanic effects
- End-of-life performance expectations and degradation rates
Engineers should evaluate each of these factors within the context of their specific mission requirements. The effectiveness of AZ-93 ESD paint as a thermal control solution depends on proper integration into the overall spacecraft design.
Early consideration of these factors during the design phase can prevent costly modifications later in the development process. Consultation with coating specialists familiar with AZ-93 ESD paint applications is recommended for critical missions with demanding thermal requirements.
Working with Modus Advanced for Your Thermal Control Solutions
At Modus Advanced, we understand the critical importance of thermal management in aerospace applications. Our team brings together deep technical expertise with practical manufacturing knowledge to support your thermal control coating needs.
Our approach to supporting your AZ-93 ESD paint requirements includes:
- Engineering consultation during the design phase
- Material selection guidance based on specific mission requirements
- Quality control processes that meet aerospace standards
- Vertical integration capabilities to streamline your manufacturing process
- AS9100 and ISO 9001 certified processes to ensure consistent quality
- ITAR compliance for sensitive projects
We believe that one day matters when lives are at stake. Our vertically integrated processes can cut weeks from your timeline without compromising the precision that your mission depends on.
Our team of engineers can work with you to determine if AZ-93 ESD paint is the optimal solution for your specific application, or if alternative thermal control strategies might better meet your requirements. This engineering-first approach ensures you receive not just a coating application, but a comprehensive thermal control solution.
The Future of Thermal Control ESD Paint in Space Applications
AZ-93 ESD paint represents a crucial technology in the thermal management toolkit for spacecraft engineers. Its proven performance in the harsh space environment makes it a reliable choice for critical applications where thermal control is essential for mission success.
As space missions become more ambitious and long-duration, the importance of stable thermal control coatings like AZ-93 ESD paint will only increase. Engineers designing the next generation of spacecraft and satellites will continue to rely on these specialized coatings to protect sensitive components and maintain optimal operating temperatures.
