LORD AM-003 Low Profile Avionics Mount: Critical Protection for Sensitive Avionics Equipment

Minute Read

Table Of Contents

    keypoints-top-border

    Key Points

    • The LORD AM-003 mount provides vibration and shock isolation for loads between 1-4.5 lbs with natural frequencies from 45-165 Hz
    • Features broad temperature range (-65°F to +300°F) BTR® silicone elastomer for consistent performance
    • Ideal for protecting sensitive electronics like guidance systems, radar components, and critical instrumentation
    • Linear deflection characteristics and low transmissibility at resonance ensure reliable isolation
    • Drop-in replacement compatibility with existing mounting patterns minimizes redesign requirements

    keypoints-bottom-border

    The LORD AM-003 Low Profile Avionics Mount represents a critical advancement in protecting sensitive aerospace and defense electronics. Whether mounted in commercial aircraft or military platforms, modern avionics systems require precise isolation from damaging vibration and shock while maintaining positional accuracy.

    COMPREHENSIVE GUIDE TO SELECTING PARKER LORD products for aerospace and defense applicationsLearn everything you need to know about Parker LORD products here!

    Technical Specifications

    The LORD AM-003 series offers engineers a range of performance characteristics to match specific application requirements:

    • Load Range: 1.0 to 4.5 lbs per mount
    • Natural Frequency Range: 45-165 Hz at rated loads
    • Maximum Dynamic Input: 0.036 inches double amplitude
    • Temperature Range: -65°F to +300°F (-54°C to +149°C)
    • Materials:
      • Inner Member: 2024-T4 aluminum
      • Outer Member: 2024-T315 aluminum
      • Elastomer: LORD BTR® or BTR® II Silicone
      • Surface Treatment: Chromate per MIL-DTL-5541, Class 1A
    • Weight: 0.34 oz (9.6g)



    This combination of materials and design produces excellent resonance control while maintaining dimensional stability across extreme temperature ranges.

    Related: Read our Guide to Parker LORD Vibration Isolation Mounts.

    Key Applications

    The LORD AM-003's precision isolation capabilities make it essential for protecting a wide range of sensitive avionics equipment across commercial and military platforms.

    The AM-003's versatile performance characteristics make it ideal for protecting:

    • Inertial navigation systems
    • Flight control computers
    • Communication equipment
    • Radar components
    • Engine monitoring systems
    • Fuel control units
    • Pressure sensors
    • Mission-critical instrumentation



    When selecting mounting locations, engineers should consider equipment center of gravity and overall system natural frequencies to optimize isolation performance.

    Design Advantages

    Engineers selecting isolation solutions for aerospace applications will find several compelling benefits unique to the LORD AM-003 mount's design and construction.

    The AM-003 provides several key benefits:

    Compact Form Factor

    Space constraints are a critical consideration in aerospace design. The AM-003's optimized geometry provides superior isolation performance while minimizing installation envelope requirements.

    The low-profile design allows for:

    • Minimal space requirements
    • Internal suspension arrangements
    • Elimination of external sway space
    • Reduced overall system weight

    Reliable Performance

    In demanding aerospace environments, consistent performance is non-negotiable. The LORD AM-003 delivers predictable isolation characteristics across a broad range of operating conditions.

    Engineers can count on:

    • Linear deflection characteristics
    • Excellent resonance control
    • Consistent behavior across temperature extremes
    • High resistance to environmental factors

    Easy Integration

    Implementing new components into existing designs often presents significant engineering challenges. The LORD AM-003's thoughtful design elements streamline the integration process.

    The mount features:

    • Drop-in compatibility with standard mounting patterns
    • Simple installation procedures
    • No special tools required
    • Minimal maintenance needs

    Installation Considerations

    Proper installation is crucial for achieving optimal vibration isolation performance. Several key factors should be evaluated during the design and implementation phases.

    When incorporating the LORD AM-003 into your design, keep these factors in mind:

    Mounting Configuration

    The effectiveness of any isolation system depends heavily on proper mount placement and load distribution. Consider these critical configuration guidelines when designing your installation.

    • Use in sets of 3 or more mounts
    • Distribute loads evenly across mounting points
    • Align with equipment center of gravity when possible
    • Consider both static and dynamic loading conditions

    Environmental Factors

    Aerospace applications expose components to extreme conditions. Understanding and accounting for environmental stresses ensures long-term mount performance and reliability.

    • Account for temperature extremes in your operating environment
    • Evaluate exposure to fluids, UV, ozone
    • Plan for altitude and pressure variations
    • Consider salt spray exposure for marine applications

    Performance Optimization

    Maximizing isolation effectiveness requires careful attention to system dynamics. These key considerations will help optimize the AM-003's performance in your application.

    • Match natural frequency to isolation requirements
    • Evaluate transmissibility needs
    • Consider shock response
    • Account for fatigue life requirements

    lord mounts resource center

    Final Thoughts

    The LORD AM-003 Low Profile Avionics Mount delivers the precision vibration control and environmental resistance needed for modern aerospace and defense applications. Its combination of proven materials, optimized design, and consistent performance makes it an ideal choice for protecting sensitive equipment in demanding conditions.
