Key Points
Before selecting a mount for your application, it's important to understand the key advantages that make the LORD AM-006 series stand out:
- Load capacity range of 10-20 lb (4.5-9.1 kg)
- Operating temperature range of -65°F to +300°F (-54°C to +149°C) with BTR elastomer
- Maximum dynamic input at resonance of 0.036 in (0.91 mm) D.A.
- Compact low-profile design for space-constrained installations
- Available in both BTR and BTR II elastomer options
These features make the AM-006 series particularly effective at protecting sensitive equipment while maintaining minimal footprint requirements.
The LORD AM-006 series of low profile avionics mounts represents a critical solution for protecting sensitive avionics equipment in aerospace and defense applications. These mounts combine compact design with superior vibration isolation capabilities, making them ideal for applications where both space and performance are crucial considerations.
Learn everything you need to know about Parker LORD products here!
Technical Specifications
Understanding the detailed specifications helps ensure proper mount selection and implementation:
Physical Characteristics
The LORD AM-006 mount's physical design balances compact dimensions with robust construction, utilizing high-grade aluminum components and protective surface treatments to ensure durability in aerospace environments.
- Weight: 0.82 oz (23.3 g)
- Inner member material: 2024-T315 aluminum
- Outer member material: 2024-T315 aluminum
- Surface finish: Chromate treated per MIL-DTL-5541, Class 1A
Performance Specifications
Understanding the performance capabilities of the LORD AM-006 series is crucial for proper application. These mounts deliver consistent vibration isolation across a wide range of conditions.
- Dynamic axial spring rate: 581-1844 lb/in (102-323 N/mm)
- Dynamic radial spring rate: 528-1676 lb/in (93-294 N/mm)
- Natural frequency: 24-43 Hz at rated load
- Transmissibility: Typically 3.5 or less at resonance
Common Applications
The AM-006 series excels in several critical aerospace and defense applications:
Primary Use Cases
The versatility of the LORD AM-006 series makes it suitable for numerous critical aerospace and defense applications where protection of sensitive electronics is paramount.
- Inertial navigation systems: Inertial navigation systems require precise vibration isolation to maintain accuracy in measuring aircraft position and movement.
- Flight control computers: Flight control computers process critical flight inputs and commands, requiring protection from vibration to ensure reliable operation.
- Radio/communications equipment: Radio and communications equipment needs isolation from engine and aerodynamic vibration to maintain clear signal transmission and reception.
- Radar components: Radar components contain sensitive electronics and moving parts that require vibration dampening to maintain target tracking accuracy.
- Critical avionics displays: Cockpit displays house delicate LCD/LED components that require isolation to maintain visual clarity and prevent damage.
- Engine monitoring systems: Environmental control components need protection from both vibration and thermal cycling while maintaining system efficiency.
These applications benefit from the mount's ability to protect sensitive electronics while maintaining precise positioning requirements.
Installation Guidelines
Proper installation is crucial for optimal performance of LORD AM-006 mounts:
Mounting Considerations
Proper mounting is essential for achieving optimal vibration isolation performance. Several key factors must be addressed during installation to ensure long-term reliability.
- Ensure mounting surfaces are clean and flat
- Verify proper torque specifications for attachment hardware
- Maintain recommended compression during installation
- Account for thermal expansion in extreme temperature applications
- Consider orientation effects on load distribution
Best Practices
Following established installation and maintenance procedures helps maximize mount performance and longevity while minimizing potential issues.
- Use all mounting points as designed
- Avoid excessive preload during installation
- Ensure adequate clearance for maximum deflection
- Verify proper load distribution across multiple mounts
- Consider environmental exposure in hardware selection
Related: Read our Guide to Parker LORD Vibration Isolation Mounts.
Selection Guide
To choose the right LORD AM-006 variant:
Key Selection Factors
Choosing the appropriate AM-006 variant requires careful consideration of several critical parameters that will impact isolation performance.
- Total equipment weight and center of gravity
- Available mounting space
- Operating temperature range
- Vibration environment
- Shock requirements
Mount Selection Process
A systematic approach to mount selection ensures the chosen variant will meet application requirements while providing optimal performance.
- Calculate total system weight
- Determine required natural frequency
- Consider environmental conditions
- Select appropriate elastomer type
- Verify spring rates match application needs
Performance Optimization
The AM-006 series performs best when properly matched to application requirements:
Optimization Considerations
Maximizing the performance of LORD AM-006 mounts requires careful attention to various application-specific factors that influence isolation effectiveness.
- Equipment weight distribution
- Operating temperature range
- Vibration input levels
- Shock requirements
- Space constraints
Proper attention to these factors ensures optimal isolation performance and equipment protection.
Maintenance and Inspection
Regular maintenance ensures long-term reliability:
Inspection Points
Regular inspection helps maintain mount performance and identify potential issues before they impact equipment protection. Key areas require specific attention.
- Visual inspection for elastomer degradation
- Check for proper mount compression
- Verify hardware torque retention
- Monitor for unusual wear patterns
- Assess environmental exposure effects
Replacement Criteria
Understanding when to replace LORD AM-006 mounts is crucial for maintaining system reliability. Several indicators help determine when replacement is necessary.
- Visible elastomer damage
- Loss of isolation performance
- Excessive permanent set
- Hardware damage or corrosion
- End of service life
Troubleshooting Guide
Common issues and their solutions:
Typical Issues
While LORD AM-006 mounts are highly reliable, certain challenges may arise during their service life. Recognizing and addressing these issues promptly ensures continued performance.
- Excessive vibration transmission
- Uneven loading
- Temperature effects
- Installation difficulties
- Performance degradation
Each issue requires systematic evaluation and appropriate corrective action to maintain optimal performance.
Final Thoughts
The LORD AM-006 Low Profile Avionics Mount series provides a robust solution for protecting sensitive aerospace equipment. With proper selection, installation, and maintenance, these mounts deliver reliable vibration isolation in demanding environments.
