Form-in-Place Gasketing: Complete Engineering Guide to Design and Implementation

August 11, 2025

Form-in-Place Gasketing: Complete Engineering Guide to Design and Implementation
Manufactured with Speed and Precision

The manufacturing capabilities you need and the engineering support you want, all from a single partner.

Submit a Design

Key Points

  • Material selection criteria: Base elastomers (silicone, synthetic rubber, fluorosilicone) with conductive fillers (nickel, copper, silver, aluminum) determine electrical and environmental performance characteristics
  • Dispensing precision capabilities: CNC-controlled systems achieve bead tolerances of ±0.15mm (±0.006 inches) height with surfaces less than 1mm wide accessible for gasket application
  • Design for manufacturability principles: Wall thickness minimums of 0.8mm (0.031 inches) for metal and 1.5mm (0.059 inches) for plastic housings prevent overflow while compression stops outperform grooves for symmetric curing
  • Curing method impact: Thermal curing at 100°C to 150°C (212°F to 302°F) for 30 minutes enables same-day testing versus moisture curing at 24+ hours at room temperature for temperature-sensitive substrates
  • Application-specific advantages: EMI shielding effectiveness >90dB, environmental sealing for IP ratings, and turnkey assembly without additional gasket installation steps
  • Manufacturing partner considerations: Vertical integration capabilities, specialized equipment access, and engineering support significantly impact project lead times and overall success

What is Form-in-Place Gasketing?

Form-in-place gasketing represents one of the most versatile sealing solutions available to engineers working on critical applications. This technology dispenses liquid elastomeric materials directly onto metal or plastic parts, creating custom gaskets that conform precisely to housing geometries regardless of surface imperfections.

Form-in-place (FIP) gaskets offer superior advantages over traditional die-cut gaskets. They eliminate dimensional constraints and material waste associated with conventional gasket manufacturing. The process creates liquid-to-solid transformation that produces gaskets with exact dimensional conformity to part geometries, including complex shapes and narrow channels that would be impossible to achieve with conventional gasket manufacturing.

The technology has evolved significantly since its introduction in the 1970s by Japanese manufacturers for engine sealing applications. Today's form-in-place systems deliver exceptional precision, environmental resistance, and electrical performance that make them indispensable for aerospace, defense, and medical device applications where reliability directly impacts mission success and patient safety.

New call-to-action

Visit our Form-in-Place Gasket Resource Center.

Form-in-Place Gasket Applications and Benefits

The technology excels in applications requiring precise dimensional control and environmental sealing. CNC dispensing systems can apply gasket material to surfaces less than one millimeter wide while maintaining consistent bead dimensions and placement accuracy. This precision enables engineers to design compact electronic enclosures with reliable sealing performance.

Primary Applications and Performance Benefits

Form-in-place gaskets serve three critical functions in modern engineering applications:

    • EMI shielding applications: Conductive gaskets provide electromagnetic interference protection with shielding effectiveness exceeding 90dB across frequency ranges from 200MHz to 40GHz
    • Environmental sealing solutions: Non-conductive formulations create reliable barriers against dust, moisture, and chemical contamination for IP65/67 rated enclosures
    • Assembly simplification: Integrated gaskets eliminate separate gasket installation steps, reducing assembly time and potential for installation errors

The aerospace and defense industries rely heavily on form-in-place technology for mission-critical electronics where EMI protection and environmental sealing cannot be compromised. Medical device manufacturers utilize the technology for life-support equipment and diagnostic systems where patient safety depends on reliable sealing performance.

Form-in-Place Gasket Advantages Over Traditional Gaskets

Form-in-place gasketing offers several key advantages compared to traditional gasket solutions:

    • No assembly required: Gaskets cure directly onto the housing, eliminating manual installation steps
    • Superior flexibility: Accommodates complex geometries and uneven surfaces that defeat conventional gaskets
    • Minimal material waste: Liquid dispensing uses only the material needed for the gasket path
    • Excellent positioning tolerances: CNC control maintains ±0.1mm (±0.004 inches) positional accuracy
    • Compartmentalized shielding: Enables isolated EMI protection between different circuit sections

Form-in-Place Gasket Materials and Selection

Successful form-in-place gasket implementation begins with understanding the relationship between base elastomer properties and conductive filler characteristics. Material selection directly impacts both electrical performance and environmental resistance in the finished gasket.

Base Materials for Form-in-Place Gaskets

Base elastomer materials provide the structural foundation and environmental resistance properties. Silicone offers superior temperature stability from -55°C to +125°C (-67°F to +257°F) with excellent UV and ozone resistance. Synthetic rubber formulations provide enhanced chemical resistance for applications involving exposure to fuels and solvents. Fluorosilicone materials combine temperature stability with exceptional chemical resistance for the most demanding environmental conditions.

Conductive Filler Systems for EMI Shielding

Conductive form-in-place gaskets require metallic filler particles to achieve electrical conductivity and EMI shielding performance. Filler selection affects both electrical properties and manufacturing characteristics:

Filler Type

Volume Resistivity

Shielding Effectiveness

Galvanic Compatibility

Cost Considerations

Silver/Copper

0.002-0.004 Ω·cm

>90dB

Excellent

High performance/cost

Silver/Aluminum

0.003-0.005 Ω·cm

>100dB

Superior corrosion resistance

Moderate premium

Silver/Nickel

0.005 Ω·cm

>100dB

Good stability

Balanced performance

Nickel/Graphite

0.03 Ω·cm

>90dB

Aluminum compatible

Cost effective

Silver-filled systems deliver the highest electrical conductivity but require consideration of galvanic compatibility with housing materials. Nickel/graphite formulations provide aluminum compatibility with enhanced galvanic corrosion resistance for severe environmental applications.

Temperature and Environmental Performance

Operating temperature ranges vary significantly between material systems and directly impact application suitability. All major form-in-place materials maintain performance across the standard -55°C to +125°C (-67°F to +257°F) temperature range required for military and aerospace applications.

Compression set characteristics determine long-term sealing effectiveness under sustained mechanical loading. Premium formulations maintain compression set below 15% after 72 hours at 100°C (212°F), ensuring reliable sealing force throughout product service life.

New call-to-action

Read the Parker Chomerics EMI Shielding Material Guide.

Form-in-Place Gasket Dispensing Technology

Form-in-place gasket manufacturing involves precise robotic dispensing systems that apply liquid elastomeric materials along predetermined paths. The process requires coordination between material handling, dispensing control, and curing systems to achieve consistent results across production runs.

CNC-Controlled Dispensing Systems

Modern dispensing systems utilize CNC control for precise needle positioning and material flow regulation. Multi-axis capabilities enable dispensing on complex three-dimensional surfaces while maintaining consistent bead dimensions and placement accuracy. Material sensors monitor flow rates and detect potential blockages before they affect gasket quality.

Form-in-place gasket dispensers incorporate advanced features for maximum precision:

    • CNC dispensing: Computer-controlled positioning ensures repeatable accuracy
    • Material sensors: Real-time monitoring prevents dispensing errors
    • Automatic rotation: Multi-axis capabilities handle complex geometries
    • Vertical dispensing: Accommodates three-dimensional gasket paths
    • Needle tip calibration: Automatic compensation for wear and thermal expansion
    • Dosing and mixing automation: Precise material ratios for two-component systems

Dispensing Path Optimization

Effective dispensing path design balances sealing requirements with manufacturing efficiency. Complex paths with multiple intersections and directional changes require extended programming time and increase the potential for dimensional variations:

    • Start/stop minimization: Reducing the number of discrete gasket segments decreases programming complexity and eliminates potential leak paths at termination points
    • Intersection management: T-joints and crossing paths create material buildup that requires careful flow control and may affect local gasket dimensions by ±30%
    • Accessibility considerations: Pocket depths exceeding 6.35mm (0.25 inches) require specialized extended-reach dispensing capabilities that increase setup time and tooling costs

Path optimization during the design phase prevents manufacturing complications that could extend lead times or require design modifications after initial prototyping.

New call-to-action

Read the Complete Form-in-Place Gasket Guide.

Form-in-Place Gasket Curing Methods

Curing method selection significantly affects both material properties and production scheduling. Understanding the impact of different curing approaches helps engineers select the optimal process for their specific requirements.

Thermal Curing for Form-in-Place Gaskets

Thermal curing systems process parts in 30-60 minutes at temperatures between 100°C to 150°C (212°F to 302°F), enabling same-day testing and shipping. This approach delivers superior mechanical properties including enhanced adhesion strength and lower compression set values.

The thermal curing process offers several advantages:

    • Faster production cycles: Parts can be tested and shipped the same day
    • Superior mechanical properties: Enhanced adhesion and reduced compression set
    • Better quality control: Consistent curing parameters improve repeatability
    • Higher throughput: Reduced cycle time increases manufacturing capacity

Moisture Curing Applications

Moisture curing systems operate at room temperature over 24+ hour cycles, making them suitable for temperature-sensitive substrates including plastic housings with cosmetic finishes or pre-installed electronic components. The extended curing time requires careful production planning but eliminates thermal stress considerations.

Design for Manufacturability in Form-in-Place Gasketing

Design for manufacturability in form-in-place applications requires understanding the relationship between housing geometry and dispensing feasibility. Early design optimization prevents manufacturing complications that could impact both lead times and production costs.

Housing Design Requirements

Housing wall thickness directly affects dispensing control and material containment. Minimum wall thickness specifications prevent gasket overflow into adjacent cavities while ensuring adequate material support during curing. Metal housings require 0.8mm (0.031 inches) minimum thickness, while plastic substrates need 1.5mm (0.059 inches) to accommodate material flexibility during compression.

Surface Preparation and Adhesion Requirements

Surface finish quality significantly impacts gasket adhesion and long-term sealing reliability. Extremely smooth finishes may require surface modification to ensure adequate bonding between the gasket material and substrate. Scribe lines or controlled surface texturing along the gasket path can improve adhesion without compromising sealing performance.

Compression stops provide superior manufacturability compared to groove designs for form-in-place applications. Grooves can cause asymmetric curing when gasket material contacts sidewalls during the curing process, resulting in irregular compression characteristics and potential sealing failures. Compression stops enable symmetric curing while providing controlled compression limits that prevent gasket damage.

Form-in-Place Gasket Tolerance Specifications

Form-in-place gasket tolerances should align with manufacturer recommendations to ensure achievable production targets. Standard height tolerances of ±0.15mm (±0.006 inches) provide reliable manufacturing capability with conventional dispensing equipment. Tighter tolerances require specialized calibration procedures that can increase lead times significantly.

Tolerance Parameter

Standard Capability

Precision Capability

Manufacturing Impact

Bead Height

±0.15mm (±0.006")

±0.08mm (±0.003")

Extended setup time

Bead Width

Height-dependent ratio

Custom requirements

Specialized programming

Position Accuracy

±0.1mm (±0.004")

±0.05mm (±0.002")

Enhanced fixturing

Custom tolerance requirements should be justified by functional necessity rather than applied as default specifications, as they directly impact both manufacturing complexity and production costs.

Form-in-Place Gasket Quality Control and Testing

Form-in-place gasket quality control encompasses both dimensional verification and performance testing to ensure sealing effectiveness and electrical properties meet application requirements. Standard inspection protocols cover gasket height, width, and basic conformance measurements using established sampling procedures.

Electrical Performance Validation

Electrical performance validation includes volume resistivity measurements and shielding effectiveness testing across specified frequency ranges. These tests verify that conductive gaskets maintain required EMI protection levels throughout their operational temperature range and after environmental exposure testing.

Standard test parameters for conductive form-in-place gaskets include:

    • Volume resistivity: Measured per MIL-DTL-83528C standards
    • Shielding effectiveness: Evaluated from 200MHz to 12GHz frequency range
    • Surface resistance: Monitored for process stability verification
    • Compression testing: Validates long-term sealing force retention

Environmental Testing Requirements

Environmental qualification testing validates gasket performance under actual service conditions including temperature cycling, humidity exposure, and chemical resistance. Salt fog testing simulates marine environments while thermal aging evaluates long-term property retention under elevated temperature conditions.

Compression set testing measures gasket recovery after sustained mechanical loading, providing data on long-term sealing force retention. This testing is particularly critical for applications where gaskets must maintain sealing effectiveness over extended service intervals without maintenance access.

New call-to-action

Choosing a Form-in-Place Gasket Manufacturing Partner

Successful form-in-place gasket implementation requires early collaboration between design and manufacturing teams to optimize both performance and manufacturability. The complexity of dispensing technology and material science makes manufacturing partner selection a critical project decision.

Vertical Integration Benefits

Vertically integrated manufacturing partners
can significantly reduce project lead times by eliminating shipping delays between machining, dispensing, and assembly operations. This approach also improves quality control by maintaining consistent processes throughout the manufacturing sequence.

Key benefits of vertically integrated form-in-place gasket manufacturing include:

    • Reduced lead times: Concurrent processing eliminates inter-vendor shipping delays
    • Improved quality control: Single quality system governs entire manufacturing process
    • Lower total costs: Elimination of multiple handling and shipping steps
    • Simplified project management: Single point of contact for entire manufacturing sequence

Engineering Support and Technical Capabilities

Manufacturing partners should provide engineering support during the design phase to identify potential manufacturing challenges before final design commitment. This collaborative approach prevents costly redesign cycles while ensuring optimal production efficiency:

  • Material selection guidance: Technical expertise in matching material properties to application requirements and environmental conditions
  • DFM optimization: Real-time feedback on housing geometry and dispensing path feasibility during design development
  • Process development: Custom dispensing trials and parameter optimization for challenging applications requiring non-standard specifications
  • Quality system integration: Documented procedures for dimensional control and performance validation that meet industry certification requirements

The learning curve associated with form-in-place dispensing technology makes experienced manufacturing partners essential for project success, particularly for applications with demanding performance requirements or tight development schedules.

New call-to-action

Visit our Design for Manufacturability Resource Center.

Final Thoughts

Form-in-place gasketing represents a mature yet continuously advancing technology that enables engineers to create reliable sealing solutions for the most demanding applications. Success requires understanding the interplay between material science, manufacturing processes, and design optimization — knowledge that comes through experience with actual production implementations.

When your innovations protect lives or enable mission-critical systems, partner with manufacturers who understand both the science and art of form-in-place gasketing. Modus Advanced combines deep technical expertise with vertically integrated manufacturing capabilities, helping engineers accelerate their path from prototype to production while maintaining the quality standards that critical applications demand.

Our engineering team — representing more than 10% of our staff — provides the technical expertise necessary for successful form-in-place gasket implementation. With AS9100, ISO 9001, and ITAR certifications, we understand the quality requirements for aerospace, defense, and medical device applications.

From initial design consultation through high-volume production, Modus Advanced delivers the engineering support and manufacturing excellence that ensures your form-in-place gasket applications perform flawlessly when it matters most. Because one day matters when lives depend on your innovation.
