NOLATO TRISHIELD® 2.0

Next Generation FIP Gasket from Nolato EMC & Thermal Solutions

Why We Work With TRISHIELD® 2.0

Trishield® 2.0 is an innovative development of the Trishield® concept that further enhances the original benefits of the Trishield® concept. Trishield® 2.0 consists of an improved forming unit and a new family of conductive elastomer materials. Trishield® 2.0 reduces the compression force required up to 80%, reduces the material usage up to 50 %, and the footprint up to 40% compared to standard D-shaped gaskets, while still providing excellent EMI shielding effectiveness. Trishield® 2.0 can either be directly installed in an existing Trishield® forming unit or as a new installment, depending on customer requirements.

Get a Quote

Key Benefits

Up to 80 % lower compression force

Short Cycle Time

Increased PCB-Area by 20%

Optimal height/width ratio (narrow gaskets)

Excellent Shielding Properties (Up to 110 dB)

NOLATO TRISHIELD® 2.0

Nolato Trishield® 2.0 8950 Form in Place EMI Shielding Gasket

The latest in Nolato’s Trishield® product offering is Trishield® 2.0. Compared to the original D-shaped gaskets, Trishield 2.0 features reduced compression force, material usage and material footprint. The improved material is a two-component thermal cure silicone filled with conductive Ni/C particles used to produce integrated EMI shielding gaskets by dispensing and forming directly on telecom or other industrial components. Trishield® 2.0 is the optimal Form in Place solution for superior shielding effectiveness and mechanical properties.

Learn More

Nolato TriShield® 2.0 8900 Form in Place EMI Shielding Gasket

Trishield 2.0 is a family of dispensed EMI shielding gaskets developed by Nolato. The material series 8990 is designed to meet the requirement in automotive applications with excellent shielding and good aging properties in rough environments.

Learn More

Nolato TriShield® 2.0 8991 Form in Place EMI Shielding Gasket

Trishield® 2.0 is an innovative development of the Trishield® concept that further enhances the original benefits of the Trishield® concept. Trishield® 2.0 consists of an improved forming unit and a new family of conductive elastomer materials.

Learn More

Quick Reference Chart

Nolato Number
Conductive Filler
Production Process
Hardness ("A")
Volume Resistivity
UL Rating
Datasheet
Nolato Number: 8950
Conductive Filler: Silicone
Production Process: Dispensing
Hardness ("A"): 45
Volume Resistivity: 25
UL Rating: V-0
Nolato Number: 8990
Conductive Filler: Silicone
Production Process: Dispensing
Hardness ("A"): 56
Volume Resistivity: 7
UL Rating: V-0
Nolato Number: 8991
Conductive Filler: Silicone
Production Process: Dispensing
Hardness ("A"): 56
Volume Resistivity: 7
UL Rating: V-0

QUESTIONS? OUR TEAM HAS ANSWERS.

With over 40 years of growth we have one of the most comprehensive arrays of advanced processes in the industry.
